Parameters:
SEPP (Singled-ended Push Pull) OTL in Class-A
Frequency response: 12 hz~100 Khz (-1dB)
THD+N: 0.15% (80 mW @300 ohm)
Power Output:
350 mW @ 300/600 ohm
300 mW @ 120 ohm
100 mW @ 32 ohm
Power Consumption: 30W (228V x 0.130A)
Variable Gain: 3,4,5, or 10x
Recommended Load Impedance: 32 ohm~600 ohm
Input Impedance: 50K ohms
Pre-Amplifier Output Impedance: 600 ohm
Pre-Amplifier Gain: 3-10x (also controlled via gain switches)
Pre-Amplifier Voltage: 10V RMS
Pre-Amplification circuit includes both driver and power tubes
Driver Tubes: 2x RTC5654
Power Tubes: 2x Soviet 6H6N (included)
High quality aluminum chassis
Dimensions (Metric): 270mm deep by 175mm wide by 123mm high
Dimensions (English): 10.6 inches deep by 6.9 inches wide by 4.8 inches
Weight: 3 Kg or 6.6 lbs
110-120V or 220-240V depending on your country
1 Year Little Dot Warranty
